SKYCOM-1550H
SKYCOM-1550H
• Frequency range: 120MHz - 600MHz
• Max 5W TX power
• >80km distance with supported ground stations
• RSSI indication
• Configurable UART TTL/RS232/RS485/RS422 channels
• Ruggedized enclosure
• High efficiency PA
• Miniaturized module
#Skycom-1550H can be sold without the enclosure for applications where size and weight are a concern.
Skycom-1550H is a Sub-GHz (120MHz - 600MHz) low-power, 0.5W - 5W transmission, long-range half-duplex communication module designed to deliver exceptional performance for a wide range of applications.
With a range of above 80 km and over the air data rates as high as 100 kbps, this versatile and configurable transceiver offers TX power of up to 5W, ensuring reliable communication for various applications.
Key Features:
- Extended Communication Range: Skycom-1550H offers an unparalleled communication range of above 80 km when paired with supported ground stations.
- Data Rate: Achieves over the air data rates of up to 100 kbps, ensuring reliable and efficient data transmission for your communication needs.
- Versatile and Configurable: The module provides flexibility for diverse applications with drop-in replacement for majority of the modems, allowing seamless integration and customization based on your requirements.
- Powerful Transmission: With a configurable TX power of up to 5W, Skycom-1550H ensures robust and clear communication over long distances.
- Low Power Consumption: Engineered for efficiency, Skycom-1550H maintains low power consumption with high-efficient power amplifier, making it ideal for remote and battery-operated deployments.
Radio specifications
| Frequency | 120MHz - 600MHz |
|---|---|
| Mode | Half-duplex |
| Modulation | FSK / GFSK / GMSK / 4FSK |
| Over the air data rate | Max 100kbps |
| TX power | 0.5W to 5W, configurable |
| Receiver sensitivity | -115dBm @BER 10-4 |
| Frequency stability | ≤±2.5ppm |
| RF port impedance | 50 Ω |
Interface specifications
| Data interface | UART TTL / RS232 / RS485 / RS422 |
|---|---|
| Baud rate | 9600, 19200, 38400, 57600, 115200 |
| Number of UART / RS232 channels | two, configurable:
(i) one for data, one for configuration & RSSI indication) (ii) one channel for data, configuration & RSSI |
General specifications
| Operating voltage | 5V to 36V |
|---|---|
| Power consumption | 1.9W (@1W TX power)
5.9W (@3W TX power) |
| Antenna connector | SMA female |
| Dimension | 70mm x 40mm x 10mm |
| Weight | 80 g with enclosure
20g without enclosure |
| Operation temperature | -40°C to 80°C |
- • Wireless telemetry
- • UAV telemetry and control
- • RTK base stations
- • Industrial IoT
- • Remote monitoring systems
